Physiotherapy Equipments (Electro Therapy Equipments)(Imported) |
 |
 |
|
Ultrasound Therapy (Donatello) |
|
 |
Duplay Disease, Tendinitis, Muscular Contractures, Analgesia, Arthrosis, Dupuytren Disease, Cicatricial Tissues, Ultrasonic Hydrolipoclasis
DONATELLO are a programmable driver units for US transducers with frequencies from 1 up to 3MHz. Through DONATELLO it is possible to obtain delivery of continuous or modulated with programmable intensity and delivery time to fit the thermo therapeutic deep treatment for different pathologic conditions.
DONATELLO has realized in the following four versions:
BASIC 1 to use 1 MHz ultrasound transducers.
BASIC 3 to use 3 MHz ultrasound transducers.
CLASSIC with automatic tuning to use ultrasound transducers in the range 1 MHz-3MHz.
SPECIAL with automatic tuning to use ultrasound transducers in the range 1 MHz-3MHz together with electrotherapeutic current.
Through Donatello it is possible to obtain delivery of Continous or Modulated ultrasound with programmable intensity and delivery time to fit the thermo therapeutic deep treatment for different pathologic condition.
DONATELLO besides its many memorized protocols, has the possibilities to memorize programs both on the unit itself and through a special software (optional).
DONATELLO transducer hand pieces can be under water used.
CHARACTERISTICS:
- High luminosity graphic display.
- Controls of the unit mode by one knob, keys or optional remote control.
- Carriage easiness for at home treatment.
- Arranged fixing of the unit to the trolley.
- More than 40 stored therapeutic protocols.
- 240 customized programs.
- Fixed frequency, automatic, or multi frequency hand pieces.
- Automatic recognition of the connected accessory.
- Associated with electrotherapy (only model special).
- Continuous or pulsated delivery.
- Output intensity (W/cm2)displayed.
- Manual memorization or PC software (optional).
- Handpiece holder provided on the unit.
- Contact Control.
| Technical Characteristics Of Donatello |
| Mains Voltage |
230 Vac/ 50-60 Hz |
| Input Power |
80 VA |
| Treatment Time |
From 1 to 30 min. |
| US frequency (Basic 1) |
1.0 MHz |
| US frequency (Basic 3) |
3.0 MHz |
| Modulation Waveform |
Continuous or pulsed (squared) |
| Duty Cycle |
From 5 up to 100% |
| Max Output Intensity |
3W/cm2 |
| Output Power |
Handpiece Dependent |
| Electric Safety Class |
1 BF |
| Handpiece IP Class |
IP67 |
| Size (W X H X D) |
280 X 380 X 230 |
| Weight |
5 |
|
|
 |
Models Available:
- BASIC 1 to use 1 MHz ultrasound transducers.
- BASIC 3 to use 3 MHz ultrasound transducers.
- CLASSIC with automatic tuning to use ultrasound transducers in the range 1 MHz-3MHz.
- SPECIAL with automatic tuning to use ultrasound transducers in the range 1 MHz-3MHz together with electrotherapeutic current.
 |
 |
|
|
|
| |
